    Energy Power PV Solar Panel 400watt 500w 550w 580w For Home Solar System

    Ask Lasest Price
    Brand Name : Gospell
    Certification : CE/TUV/ISO/IEC
    Price : US$0.3/watt
    Payment Terms : T/T, Western Union
    Supply Ability : 300000000 Watt/Watts per Month
    Delivery Time : 8-12 working days
    • Product Details
    • Company Profile

    Energy Power PV Solar Panel 400watt 500w 550w 580w For Home Solar System

    Solar Photovoltaic PV Energy Power Solar Panel 400watt 500w 550w 580w for home solar system



    Solar module features

    Multi Busbar Technology
    Better lighttrapping and current collection to improve,Effectively improvethe module's power output and reliability
    Higher output power
    Module output power increased to 505W
    Low light performance
    The special solar cell technology has excellentlow light power generationperformance.
    Better resistance to hot spots
    The use of half cell structure andspecial circuit design is lessshade loss, withbetter temperature coefficient and thermal spot resistance ability
    Adaptability to harsh environments
    High performance materials are suitable for coastal, farm, desert and otherharsh environmental conditions,glass surface is anti-reflective and easy toclean, minimizing powergeneration losses caused by dirt and dust.

    Product Paramenters


    ELECTRICAL DATA (STC)
    Peak Power Watts-PMAX (Wp)
    390
    395
    400
    405
    Maximum Power Voltage-VMPP (V)
    33.8
    34.0
    34.2
    34.4
    Maximum Power Current-IMPP (A)
    11.54
    11.62
    11.70
    11.77
    Open Circuit Voltage-VOC (V)
    40.8
    41.0
    41.2
    41.4
    Short Circuit Current-ISC (A)
    12.14
    12.21
    12.28
    12.34
    Module Effciency η m (%)
    20.3
    20.5
    20.8
    21.1
    Power Tolerance-PMAX (W)
    0 ~ +5
    Front Glass
    3.2mm (0.13 inches), High Transmission, AR Coated Heat Strengthened Glass
    Frame
    30mm(1.18 inches) Anodized Aluminium Alloy
    WARRANTY
    12 year Product Workmanship Warranty,25 year Power Warranty
    PACKAGING CONFIGURATION
    Modules per box: 36 pieces,Modules per 40’ container: 936 pieces
    ELECTRICAL DATA (NOCT)
    Maximum Power-PMAX (Wp)
    295
    298
    302
    306
    Maximum Power Voltage-VMPP (V)
    31.8
    32.0
    32.2
    32.5
    Maximum Power Current-IMPP (A)
    9.26
    9.32
    9.38
    9.41
    Open Circuit Voltage-VOC (V)
    38.4
    38.6
    38.8
    38.9
    Short Circuit Current-ISC (A)
    9.78
    9.84
    9.90
    9.95
    Module Dimensions
    1754 ×1096×30 mm (69.06×43.15×1.18 inches)

    Product Description



    SYSTEM & PRODUCT CERTIFICATES·IEC 61215 /IEC 61730/IEC 61701/IEC 62716
    ISO 9001: 2015 Quality Management System
    ISO 14001: 2015 Environment Management System
    ISO 45001: 2018 Occupational Health and Safety Management Systems


    ​​

    Quality Energy Power PV Solar Panel 400watt 500w 550w 580w For Home Solar System for sale
