Product Overview
GN-1866B is a cost-effective 4K multi-channel HEVC digital TV
encoder with broadcast quality.
With 2/4/6/8/10/12 audio and video input ports, it can complete
multiple 4K+2K HEVC high-definition low bit rate encoding.
Each daughter board independently supports 2 channels of audio and
video encoding, and outputs through 1 IP channel.
This product is easy to operate, easy to install and maintain.
Provide a web-based visual management and maintenance interface.
The product can provide high-quality and highly reliable HD and SD
video services in different front-end applications.
For operators who mainly adopt or purchase programs from
higher-level operators and have a small amount of independent
program sources.
When using this product to build a digital TV front-end, not only
can the cost be reduced, but the front-end construction can be
completed in a short time
Main Features
-With independent 2/4/6/8/10/12 video and audio input ports (HDMI
interface, support the number of channels can be customized
according to user needs).
-Supports up to 6 channels of 4K + 6 channels of 2K HEVC audio and
video encoding.
-High-quality HEVC (H.265)/H.264 video high-definition compression
coding can be realized.
-Support fixed bit rate (CBR) and variable bit rate encoding (VBR).
-Support resolutions of various commonly used formats.
-Support AC3 Bypass, MPEG-1 L2, AAC audio encoding methods.
-Support: automatic, 32KHz, 44.1KHz, 48KHz input audio sampling
rate.
-The OLED front panel and LED indicator are used as displays to
display device information and device status.
-The parameters can be set and upgraded through the WEB browser.
-With fault alarm display.
-With power-down memory function.
| Number of ports | 2 |
| IP data interface (single daughter board) |
| Number of ports | 1 |
| Socket type | RJ-45 100/1000 Base-T |
| Format | MPEG TS-over-IP |
| Output Resolution | Automatic 3840*2160P30 1920*1080P25 1920*1080P30 1920*1080P50 1920*1080P59.94 1920*1080P60 1280*720P30 1280*720P25 1280*720P50 1280*720P59.94 1280*720P60 576P25 480P29.97 |
| Output bit rate (single sub-board) | |
| Output bit rate | 1~30Mbps(SPTS) 60Mbps(MPTS) |
| Management (single sub-board, shared with data ports) |
| Socket type | RJ-45 100/1000 Base-T |
| Number of ports | 1(Share with data port) |
| Power consumption |
| Input voltage range | 110 - 240V AC |
| Input frequency range | 50/60Hz |
| Power consumption | ≤75W |
| Environment |
| Working Temperature | 0℃ - 45℃ |
| Storage Temperature | -20℃ - 80℃ |
| Humidity | 10% - 90%,No condensation |
| Physical index |
| Size(W x H x D) | 483mm×44.5mm×400mm
|
| Weight | ≤5.0kg |
