    SD IPTV OTT Headend Digital TV Encoder HD H264 To Ethernet IP Video Live Streaming One Stop Solution

    Ask Lasest Price
    Brand Name : GOSPELL
    Model Number : GN-1898C
    Certification : ISO9001,FCC,CE
    Delivery Time : 2 weeks
    • Product Details
    • Company Profile

    SD IPTV OTT Headend Digital TV Encoder HD H264 To Ethernet IP Video Live Streaming One Stop Solution

    Product Overview


    GN-1898 is the latest MPEG-2/MPGE-4 AVC high efficiency SD encoder.

    It can perform SD MPEG-2/MPEG-4 AVC compression encoding of up to eight channels of analogue or digital A/V input signals simultaneously.


    Then output the signals through IP interface after multiplexing.

    This unit can be used for A/V signal source encoding of a DTV network head-end system, and it also supports WEB/SNMP management.



    Main Features


    l Up to eight channels of MPEG-2/MPEG-4 AVC SD encoding in 1RU;

    l MPEG-1 Layer II or AAC(license option) audio encoding;

    l Up to eight channels of analog composite video and unbalanced audio pairs inputs or digital SDI video with embedded stereo audio inputs;

    l High picture quality in ultra low bit rate to reduce network overheads or costs;

    l Web browser GUI and SNMP interface for remote management and control;

    l MPEG TS-over-IP (7 x 188 Byte) output, supporting MPTS/SPTS mode

    l Supports single IP output

    l MPEG-2 encoding rate range from 0.5 to 5.5Mbps each video

    l MPEG-4 AVC encoding rate range from 0.25Mbps to 5.5Mbps each video

    l Supports multiple PAL and NTSC standard definition video encoding resolutions

    l VBR/CBR video encoding

    l Supports simple TS multiplex with auto-generated PSI/SI

    l Low power consumption

    l Front panel control and LCD display



    Technical Specifications


    Video/Audio Input Options
    Analog Video/Audio Input Option*
    Composite Video8 x CVBS
    BNC female, 75W
    Unbalanced Audio8 x Stereo pairs (R&L)
    BNC female, 600W
    Stereo or Mono mode
    Digital Video/Audio Input Option*
    Serial Digital Interface

    8 x SD-SDI (BNC female, 75W)

    SMPTE 259M

    AudioEmbedded in SD-SDI
    Notes: Analog input option and digital input option are not available simultaneously.
    ASI Transport Stream Input
    Number of ASI Input1 x ASI Input and 1 x ASI Loop Out
    ConnectorBNC female, 75W
    TS Packet Length188 or 204 Bytes
    Effective Input Rate60Mbps (maximum)
    Burst TSNot support
    MPEG TS Over IP Output*
    Number of IP Output1 x 10/100 Base-T Ethernet
    Output ModeRedundant output
    MPEG TS Format7 x 188Byte
    IP EncapsulationMPEG TS-over-UDP
    MPEG TS ModeMPTS or SPTS
    Number of TS Output8 TS
    AddressingUnicast or Multicast
    ConnectorRJ-45

    Notes: 1) TS-over-IP output and ASI outputs will be available simultaneously in MPTS mode; TS-over-IP output will be available but ASI outputs will be not available in SPTS mode;

    2) Only one IP output interface will be available when enable ASI input.

    Video Encoding
    Encoding Formats

    MPEG-2: MP@ML

    MPEG-4 AVC: MP@L3

    Resolution and Frame Rate720/704/640/544/352 x 576i@25fps, 720/704/640/544/352 x 480i@29.97fps
    Aspect Ratio1:1, 4:3, 16:9
    Encoding Rate ModeCBR, VBR
    Video ControlBrightness, Contrast, Chrominance and Hue
    Video Encoding Rate

    MPEG-2: 0.5 to 5.5Mbps per program

    MPEG-4 AVC: 0.25 to 5.5Mbps per program

    Watermark function
    Watermark image formatPNG format
    Superimposed channel8 CH
    Transparency adjustment range0~100
    Audio Encoding
    Encoding Standards

    MPEG-1 Layer 2

    Optional: AAC

    Operation ModeStereo or Mono
    Volume Control-63dB to +20dB
    Sample Rate32 kHz, 44.1 kHz, 48 kHz
    Audio Encoding Rate

    MPEG-1 Layer II: 192/224/256/320/384 kbps

    Optional AAC: 96/112/128/160/192/ 224/256/320/384 kbps

    Network Management
    Interface1 x 10/100 Base-T Ethernet
    ConnectorRJ-45
    ManagementWeb browser and SNMP management
    Miscellaneous
    Front Panel3.5’’ LCD with 6 x Control Button for 2-lines information display and settings
    3 x Dual color LED, for status indications of power, working and Alarm
    Rear Panel1 x 3-Pin Receptacle(AC Input)
    1 x Power switch
    1 x Serial Console Port(via RJ-45 connector)
    Power Supply
    Input Voltage90 - 250 VAC, 50/60Hz
    Power Consumption55W (Maximum)
    Environmental
    Operating Temperature5℃ to 45℃(41℉ to 113℉)
    Storage Temperature-25℃to 70℃(-13℉ to 158℉)
    Operating Humidity90%, non-condensing
    Mechanical

    Product Dimensions

    (W x H x D)

    483mm x 44.5mm x 400mm

    19’’ x 1.73’’ (1 RU) x 15.8’’

    Product Weight5Kg (11 lbs)
