    MSDS Solar Energy Storage System 48V 200ah 400ah 10kwh 20kwh LiFePO4 Battery Pack

    Ask Lasest Price
    Brand Name : Gospell
    Certification : CE / Un38.3/ MSDS
    Price : US$1980/pc
    Payment Terms : T/T, Western Union
    Supply Ability : 100000 Pieces Per Month
    Delivery Time : 10-15 working days
    • Product Details
    • Company Profile

    MSDS Solar Energy Storage System 48V 200ah 400ah 10kwh 20kwh LiFePO4 Battery Pack

    New 48V 200ah 400ah 10kwh 20kwh Lithium Batteries for 48V 200ah 250ah LiFePO4 Battery Pack and Solar Energy Storage


    Product details​​
    Model
    5.0S
    10.0S
    15.0S
    20.0S
    Battery Moudule
    1
    2
    3
    4
    Battery Energy
    5.12kWh
    10.24kWh
    15.36kWh
    20.48kWh
    Battery Capacity
    100AH
    200AH
    300AH
    400AH
    Weight
    80kg
    133kg
    186kg
    239kg
    Dimension L* D* H
    710*450*400
    710*450*600
    710*450*800
    710*450*1000
    Battery Type
    LiFePO4
    Battery Rated Voltage
    51.2V
    Battery Working Voltage Range
    44.8 ~57.6V
    Maximum Charging Current
    100A
    Maximum Discharging Current
    100A
    DOD
    0.8
    Parallel Quantity
    4
    Designed Life-span
    6000
    PV CHARGE
    Solar Charge Type
    MPPT
    Maximum Output Power
    5KW
    PV Charging Current Range
    0~80A
    PV Operating Voltage Range
    120~500V
    MPPT Voltage Range
    120~450V
    AC CHARGE
    Maximum Charge Power
    3150W
    AC Charging Current Range
    0~60A
    Rated Input Voltage
    220/230Vac
    Input Voltage Range
    90~280Vac
    AC OUTPUT
    Rated Output Power
    5KW
    Maximum Output Current
    30A
    Frequency
    50Hz
    Overload Current
    35A
    BATTERY INVERTER OUTPUT
    Rated Output Power
    5KW
    Maximum Peak Power
    10KVA
    Power Factor
    1
    Rated Output Voltage (Vac)
    230Vac
    Frequency
    50Hz
    Auto Switch Period
    <15ms
    THD
    <3%
    GENERAL DATA
    Communication
    RS485/CAN/WIFI
    Storage time / temperature
    6 months @25ºC;3 months @35ºC;1 months @45ºC;
    Charging temperature range
    0~45ºC
    Discharging temperature range
    -10~45ºC
    Operation Humidity
    5% ~ 85%
    Nominal Operation Altitude
    <2000m
    Cooling Mode
    Force-Air Cooling
    Noise
    60dB(A)
    Ingress Protection Rating
    IP20
    Recommended Operation Environment
    Indoor
    Installation Method
    Horizontal
    Certification
    UN38.3,MSDS,EN55032,EN55024,EN61000-3-2,EN61000-3-3
