    330W - 460W Solar Energy Storage System Half Cell Monocrystalline Silicon PV Module

    Ask Lasest Price
    Brand Name : Gospell
    Certification : TUV
    Price : US$0.7/watt
    Payment Terms : T/T, Western Union
    Supply Ability : 300000000 Watt/Watts per Month
    Delivery Time : 8-12 working days
    • Product Details
    • Company Profile

    330W - 460W Solar Energy Storage System Half Cell Monocrystalline Silicon PV Module

    High-efficiency solar panel Polycrystalline Silicon 330W 340W 350W 410W 460W all black Solar Power Panels for Home Electricity



    Product Paramenters

    435~455MH5-60 Half-Cell Monocrystalline Silicon PV Modules Mechanical Data
    Cell Type
    182×91mm Mono
    Cell Orientation
    120(6×20)
    Module Dimensions
    1909×1134×35mm
    Weight
    25.0kg
    Glass
    3.2mm high transmittance, reinforced glass
    Backsheet
    Anti-aging film
    Frame Material
    Anodized aluminum alloy
    Junction Box
    Protection class IP68
    Cable
    4.0 mm2positive pole: 300 mm negative pole: 400 mmwire length can be customized
    Connector
    MC4 compatible connector
    Modules Per Pallet
    31+31pcs
    Modules Per 40'HQ Container
    744pcs

    Product Description



    SYSTEM & PRODUCT CERTIFICATES·IEC 61215 /IEC 61730/IEC 61701/IEC 62716
    ISO 9001: 2015 Quality Management System
    ISO 14001: 2015 Environment Management System
    ISO 45001: 2018 Occupational Health and Safety Management Systems


    Electrical Data (STC)
    Maximum Power (Pmax/W)
    435
    440
    445
    450
    455
    Voltage at Maximum Power (Vmp/v)
    33.76
    33.91
    34.06
    34.21
    34.36
    Current at Maximum Power (Imp/A)
    12.89
    12.98
    13.07
    13.16
    13.25
    Open Circuit Voltage (Voc/M)
    40.80
    40.95
    41.10
    41.25
    41.40
    Short Circuit Current (Isc/A)
    13.34
    13.41
    13.52
    13.62
    13.72
    Module Efficiency (%)
    20.09
    20.33
    20.56
    20.79
    21.02
    STC(Standard Testing Conditions): lrradiance 1000W/m2, Cell Temperature 25*C,AM1.5

    Electrical Data (NMOT)
    Maximum Power (Pmax/w)
    326
    330
    334
    338
    342
    Voltage at Maximum Power (Vmp/M)
    31.19
    31.34
    31.49
    34.61
    31.79
    Current at Maximum Power (Imp/A)
    10.46
    10.54
    10.62
    10.69
    10.77
    Open Circuit Voltage (Voc/V)
    37.61
    37.76
    37.91
    38.06
    38.21
    Short Circuit Current (Isc/A)
    11.11
    11.19
    11.28
    11.36
    11.45
    NMOT (Nominal Moudule Operating Temperature): Iradiance 800W/m , Ambient Temperature 20'C,AM1.5, Wind Speed 1m/s.

    Temperature Coefficients
    Operating Parameters
    Temperature Coefficient(Pm)
    -0.350%ºC
    Maximum System voltage
    1000/1500v
    Temperature Coefficient(Voc)
    -0.270%ºC
    Operating Temperature
    -40ºC~+85ºC
    Temperature Coefficient(Isc)
    -0.048%ºC
    NMOT (Nominal MouduleOperating Temperature)
    41+3ºC
