4K UHD Video Transmission System With 1600FT Range Low Delay Wireless Video Transmitter And Receiver

    Buy cheap 4K UHD Video Transmission System With 1600FT Range Low Delay Wireless Video Transmitter And Receiver from wholesalers

    Buy cheap 4K UHD Video Transmission System With 1600FT Range Low Delay Wireless Video Transmitter And Receiver from wholesalers
    • Buy cheap 4K UHD Video Transmission System With 1600FT Range Low Delay Wireless Video Transmitter And Receiver from wholesalers
    • Buy cheap 4K UHD Video Transmission System With 1600FT Range Low Delay Wireless Video Transmitter And Receiver from wholesalers
    • Buy cheap 4K UHD Video Transmission System With 1600FT Range Low Delay Wireless Video Transmitter And Receiver from wholesalers

    4K UHD Video Transmission System With 1600FT Range Low Delay Wireless Video Transmitter And Receiver

    Ask Lasest Price
    Brand Name : OEM
    Model Number : 4k transmission
    Certification : CE, ROHS, FCC
    Price : $9499/set
    Payment Terms : T/T, L/C, Western Union, MoneyGram, D/P
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    4K UHD Video Transmission System With 1600FT Range Low Delay Wireless Video Transmitter And Receiver

    4K UHD Video Transmission System with 1600FT Range Low Delay Wireless Video Transmitter and Receiver Support 12g-SDI 10


    Features


    Wireless transmission up to 800ft.


    Latency as low as 70ms.


    Support a wide variety of resolution formats up to 1080p60Hz.


    Support SDI input, SDI loop out, dual SDI output, HDMI input and output.


    Support App monitoring.


    Up to 25Mbps bit rate.


    As many as 4 smartphones/iPads can be connected to the transmitter.


    DC/SONY NP-F battery/power bank, any of which can serve as a power source.


    Versatile OLED screen displays battery status, fan status, resolution, signal strength, work mode and channel.


    Fans can be shut down to eliminate the noise if necessary.


    The App comes with a wide variety of visual effects.


    Compact and portable.


    Detailed Photos



    Specification


    Operating Frequency
    5.1GHz-5.8GHz (11 frequencies)
    Operating bandwidth
    40MHZ
    Output Power
    23 dBm
    Receiving Sensitivity
    ,-94dbm
    Antenna Mode
    4*4 MIMO 5dBi External Antenna
    Network encryption
    WPA2 / WPS/AES-128
    Transmission Distance
    Omni-directional antenna 500 meters (50Mbps line-of-sight)
    Receive plus flat panel antenna 970 meters (30Mbps line-of-sight)
    Video Compression Format
    H.265
    Sampling rate 4:2:2 10bit
    Supported
    APP Management
    Not Supported
    Multi-Receiver
    Not Supported
    Time Code Transmission
    Not Supported
    Input cross conversion
    Not Supported
    Video format conversion
    Not Supported
    Audio Encoding
    MPEG-AAC audio encoding, sampling rate: 44.1/48kHz
    Video delay
    70ms
    Camera control signal RS232 or RS422 control transmission
    Supported
    Tally light signal transmission
    Supported
    Intercom voice intercom
    Supported
    Upgrade function
    Supported
    Transmission protocol (RTSP/RTP streaming)
    Supported
    Interface
    HD in*1
    SDI in*1
    SDI loopout*1
    USB Type-C
    DC power socket
    RS232(RJ45) port
    Intercom port (3.5mm headphone port) Tally port (3.5mm headphone port)
    RJ45 network port
    Resolution Support (SDI)
    4096x2160 23.98/ 24/25/29.97/30/50/59.94/60Hz
    3840x2160 23.98/ 24/25/29.97/30/50/59.94/60Hz
    1080P 60/59.94/50Hz(3GA&3GB)
    1080i 60/59.94/50Hz
    1080P 30/29.97/25/24/23.98Hz
    1080PsF 29.97/25/24/23.98Hz
    720P 60/59.94/50Hz
    Resolution Support (HDMI)
    4096x2160 23.98/ 24/25/29.97/30/50/59.94/60Hz
    3840x2160 23.98/ 24/25/29.97/30/50/59.94/60Hz
    1080P 60/59.94/50/30/29.97/25/24/23.98Hz
    1080i 60/59.94/50Hz
    720P 60/59.94/50Hz
    Display and buttons
    Support display network connection status, video resolution, battery power and other statuses
    Support function menu operation settings (sweep, upgrade, high/low gain switching, voice intercom, video bit rate, serial port
    baud rate, fan control, etc.)
    Voltage Operating Range
    9-36V
    Operating Environment
    Temperature: -10ºC~+55ºC; Humidity less than or equal to 95% (no condensation)
    Product Certification
    FCC, CE
    Dimension
    185X117X40mm
